Morgiee · 22nd February 2009, 15:29

hi ive customised the boot of my car however im required to install two 12v fans to cool the amplifier. could someone tell me where i wire the fans to. im wanting them to turn on when i start my ignition and switched off when i turn off my ignition. i dont want them on coinstant as this will flattern the battery.

bellow is a pic of the fans and all wiring to help you. could some one go through step by step (with pics if possible) on how to wire them up.

thanks

shaunyboy · 22nd February 2009, 16:42

cut the molex connector off so you have a red + black wire now if i remember correctly you can run it off the remote wire so it comes on with the amp. Pred will be able to tell you

reevesy_vtr · 22nd February 2009, 16:43

you only need the red and the black wires that come from the fan. You can get rid of all the other wiring.

Matty_VTR · 22nd February 2009, 16:57

Red to remote 12v
Black to ground

sorted

saxovtsmad · 22nd February 2009, 17:02

just connect them to your amp live and ground thats what id do with the red and black wires and turn ignition on se if they work then turn it off and see if they go off

Morgiee · 22nd February 2009, 17:10

cool ill give that a try tomorrow thats for your replies really aprishiate it

shaunyboy · 22nd February 2009, 18:31

Quote:

Originally Posted by Matty_VTR

Red to remote 12v
Black to ground

sorted

thats the one

Lozza_vtr · 22nd February 2009, 18:35

I always thought that you should run fans etc from a separate relay?

Cooling fans

shaunyboy · 23rd February 2009, 01:53

if you want to go down the relay route a good bit is at the bottom of this page

http://www.caraudiobook.com/car_audi...components.htm

if you dont know what your doing you may find it hard to wire it up that way.

Coonper · 23rd February 2009, 08:14

DO NOT, i repeat, DO NOT run fans off your remote cable!

This is not intended to run proper amperage! Most head untis have remote turn on systems rated at 0.3amps, which is enough to send a signal, but nowhere near enough to actually power something up! Granted it will work, but for how long im not sure. The head unit will blow up prematurely.

Run them off the ignition live wire, which is the red one behind your head unit.

This will enable the fans to turn on and off with the ignition. You could also put a switch in the live cable so you can turn them off when you want.

But dont power the fans off the remote!

shaunyboy · 23rd February 2009, 18:26

hence the reason for a relay

AlexGreen · 23rd February 2009, 18:45

Relay!
